Key features
Choice of motor sizes from 0.25 to 1.0 Horsepower
Three phase (T) models now available
Suitable for small to medium pools
Manufactured in Europe
Two year guarantee
Self-priming pump that offers excellent hydraulic performance, premium build quality and quiet operation
Pump body and mechanical seal are resistant to chemicals and salt water
Transparent, polycarbonate lid for inspecting pre-filter basket
Large pre-filter prevents floating debris from damaging the pump or connected equipment
1½ inch solvent socket unions (Note: Imperial measurement is internal bore of pipe)
Downloads
Specifications (.pdf)
Manual (.pdf)
Specifications
Model |
Optima 25 |
Flowrate Max. |
167 L/min (10 m³/h) |
Head Max. |
12m |
Horse Power |
0.25 HP |
Power Output |
0.16 kW |
Voltage |
230V/400V |
Water Temp Max. |
40°C |
Motor Speed |
2900 RPM |
Discharge Size |
1½ inch |
Suction Size |
1½ inch |
Weight |
9.5 Kg |
Dimensions (H x W x L) |
265mm x 191mm x 470mm |
Model |
Optima 33 |
Flowrate Max. |
200 L/min (12 m³/h) |
Head Max. |
12m |
Horse Power |
0.33 HP |
Power Output |
0.25 kW |
Voltage |
230V/400V |
Water Temp Max. |
40°C |
Motor Speed |
2900 RPM |
Discharge Size |
1½ inch |
Suction Size |
1½ inch |
Weight |
9.5 Kg |
Dimensions (H x W x L) |
265mm x 191mm x 470mm |
Model |
Optima 50 |
Flowrate Max. |
233 L/min (14 m³/h) |
Head Max. |
12m |
Horse Power |
0.5 HP |
Power Output |
0.37 kW |
Voltage |
230V/400V |
Water Temp Max. |
40°C |
Motor Speed |
2900 RPM |
Discharge Size |
1½ inch |
Suction Size |
1½ inch |
Weight |
10 Kg |
Dimensions (H x W x L) |
265mm x 191mm x 470mm |
Model |
Optima 75 |
Flowrate Max. |
267 L/min (16 m³/h) |
Head Max. |
14m |
Horse Power |
0.75 HP |
Power Output |
0.55 kW |
Voltage |
230V/400V |
Water Temp Max. |
40°C |
Motor Speed |
2900 RPM |
Discharge Size |
1½ inch |
Suction Size |
1½ inch |
Weight |
10.5 Kg |
Dimensions (H x W x L) |
265mm x 191mm x 470mm |
Model |
Optima 100 |
Flowrate Max. |
300 L/min (18 m³/h) |
Head Max. |
14m |
Horse Power |
1.0 HP |
Power Output |
0.75 kW |
Voltage |
230V/400V |
Water Temp Max. |
40°C |
Motor Speed |
2900 RPM |
Discharge Size |
1½ inch |
Suction Size |
1½ inch |
Weight |
10.5 Kg |
Dimensions (H x W x L) |
265mm x 191mm x 470mm |
Construction
Pump body, pump body lid and diffuser in polypropylene and reinforced with glass fibre guaranteeing excellent duration
Shaft in stainless steel AISI 316
Noryl impeller
Transparent lid in polycarbonate
Support-base in aluminium
Mechanical seal in carbon-ceramic and stainless steel AISI 316
Bolts in stainless steel AISI 304
Standard asynchronous motor, sealed from external ventilation
Protection IP55, Class F insulation
Motor bearings greased for life
Maximum water temperature +40°C
