Key features
The power of Full Inverter & EVI efficiency right down to -25°C
Integrated remote colour touchscreen can be removed from the unit (wired)
Up to 5.2kW of heat output at air temperature of 26°C and water temperature of 26°C
Up to 4.39kW of heat output at air temperature of 15°C, water temperature of 38°C
Up to 3.1kW of heat output at air temperature of -10°C, water temperature of 38°C
Can be installed on any spa, hot tub, swim spa, or Nordic bath (size dependent)
Operates down to -25°C, automatic de-icing
Reversible hot/cold for ultimate flexibility, can be used to heat or cool
Heating range from 15 – 43°C, cooling range from 5 – 43°C
Wi-Fi for easy remote control via the dedicated Poolex app, available for both iOS and Android smartphones
Plug and play – comes with mains cable and RCD
32/38mm hose tail water connections, pipes, and other fittings not supplied
Integrated control of the spa / hot tub heater and/or auxiliary heat pump (relay/s optional)
R32 Refrigerant
Supplied with RCD mains cable, anti-vibration pads, 32/38mm hose tails, 2 x hose clips and winter cover
Three-year parts warranty, seven-year parts (total) on compressor, and 15-year corrosion (total) on Titanium coil
Downloads
Specifications (.pdf)
Manual (.pdf)
Specifications
Heating Capacity A26/W26 |
2.95~5.2kW |
Power Consumption |
0.34~0.67kW |
COP |
8.6~7.6 |
Heating Capacity A15/W38 |
2.05~4.39kW |
Power Consumption |
0.4~0.67kW |
COP |
5.1~4.7 |
Heating Capacity A-10/W38 |
0.97-3.1kW |
Power Consumption |
0.36~1.38kW |
COP |
2.64-2.24 |
Maximum Power |
2.1kW |
Voltage |
230v |
Noise Level (10m) |
<35dB(A) |
Refrigerant |
R32 |
Water Connections |
32-38mm |
Nominal Flow |
2.15 m³/h |
Dimensions (L x W x H) |
540mm x 490mm x 430mm |
Weight |
42Kg |
What is COP?
COP stands for Coefficient of Performance
COP is quoted as a number, such as 5.2
For each kW of energy input, 5.2 x kW would be output
The higher the output, the lower the running costs
Installation
All models are fitted with a mains cable, RCD and plug as standard, making them suitable for outdoor sockets.
Water inlet and outlet connections are 32-38mm, two hose tails are supplied as standard, however you may require additional hose and fittings to connect to your spa or hot tub. The Ice Spa should be connected after your spa’s circulation pump and heater, the use of a bypass kit (normally made up of 2 x T-pieces and 3 x ball valves) is recommended.
Supplied with RCD mains cable, anti-vibration pads, 2 x 1″ / 32-38mm hose tails, 2 x hose clips and winter cover
Your Poolex Ice Spa heat pump should always be installed outside, restrictions on air flow around a heat pump such as dense vegetation or solid surfaces such as sheds, fences or walls will lead to a drop in efficiency and heating ability, it especially important that cooled air can be properly dispersed away from the unit.
While the casing provides protection from the weather, the Ice Spa should be disconnected and stored in a shed or garage if not in use for extended periods.
