Key features
Highest UV reflective index on the market equating to supreme efficiency
Optional smart peristaltic dosing system for chlorine/hydrogen peroxide
E-PTFE reaction chamber is extremely repellent, maintaining UV reflectivity
Up to 95% reflection amplifying the exposure of microorganisms to UV
No harmful gases or by-products produced
Neutralises bacteria, viruses, algae and fungai that traditional chemicals cannot
Powerful sterilisation and eliminates the smell of chlorine
Average lamp life expectancy: 2 years
Equipped with intelligent lamp life indicator
Salt and sea water compatible
Made in the U.K.
Downloads
Specifications (.pdf)
Manual (.pdf)
Technical data
Power: 100V ~ 240V
Min, flow rate: 4m³/h
Max. flow rate: Single Tube: 21,000 litres per hour; 21 m³/h / Double Tube: 42,000 litres per hour; 42 m³/h
Max. pool size: Single Tube: 50,000 litres; 50m³ / Double Tube: 100,000 litres; 100m³
Max. power consumption: Single Tube: 64W / Double Tube: 128W
Lamp: Low pressure / high output
Lamp life: 9,000 hours
Dosing rate: Exceeds the equivalent of 30mj/cm² at max. flow rate
Protection: IP64
Working pressure: 3 Bar maximum
Water connections: 2 inch / 63mm stepped ABS unions + reducers 1½ inch / 50mm
Salt water: 100% sea water safe
Mounting: Floor or wall mounting
Oxidisation process: UV
