Key features
Highest UV reflective index on the market equating to supreme efficiency
E-PTFE reaction chamber is extremely repellent, maintaining UV reflectivity
Up to 95% reflection amplifying the exposure of microorganisms to UV
No harmful gases or by-products produced
Neutralises bacteria, viruses, algae and fungai that traditional chemicals cannot
Powerful sterilisation and eliminates the smell of chlorine
Average lamp life expectancy: 2 years
Salt and sea water compatible
Made in the U.K.
Downloads
Specifications (.pdf)
Manual (.pdf)
Technical data
Power: 100V ~ 240V
Min, flow rate: 1.5m³/h
Max. flow rate: 12,000 litres per hour; 12 m³/h
Max. pool size: 30,000 litres; 30m³
Max. power consumption: 40W
Lamp: Amalgam
Lamp life: Up to 14,000 hours
Dosing rate: Exceeds the equivalent of 30mj/cm² at max. flow rate
Protection: IP65
Working pressure: 3 Bar maximum
Water connections: 2 inch / 63mm stepped ABS unions + reducers 1½ inch / 50mm
Salt water: 100% sea and salt chlorinated water safe
Mounting: Vertical or horizontal wall mounting
Oxidisation process: UV
