The HM DN65 from AF Pumps features tough construction and a single channel closed impeller, offering reliability against clogging, the DN65 flange offers wide through sections, with 40mm free passage and good resistance to wear.
The HM pumps are particularly suited to pumping clear and waste water including sewage, containing solids, fibrous solids and sludge.
The single phase model is available with manual or automatic operation, the three phase model has manual operation and features Klixon and water in oil chamber alarm outputs.
The HM has a horizontal DN65 flanged discharge, an optional claw can be fitted for use on guide rails, the maximum flow rate is 1,000 litres per minute, and the maximum head is 22m.
AF Pumps are sold exclusively by Automated Environmental Systems in the UK.
Key features
Maximum flow 1,000 litres per minute, maximum head 22m
Maximum temperature of pumped fluid 40°C
PH of pumped fluid 6-10
DN65 discharge offers reliability against clogging
Single channel closed impeller
Free passage up to 40mm
230v manual and automatic operation, 400v manual operation
Three phase models feature Klixon and water in oil chamber alarm outputs
Single-phase motor protector and capacitor in box control, three-phase with compulsory protection to be provided by the user
Electric cable neoprene H07RN8-F with free therminals
Bolt A2 class AISI 304
O’ring nitrile
Shaft sealing by two mechanical seals mounted in series in ecologic oil chamber
Seal types applied to the motor side on ceramic/graphite and seal types applied to the wet end side on silicon carbide
Motor asynchronous squirrel cage type in dielectric anti-oxide oil bath
Protection IP 68 and insulation class F
Product Description
The HM DN65 from AF Pumps features tough construction and a single channel closed impeller, offering reliability against clogging, the DN65 flange offers wide through sections, with 40mm free passage and good resistance to wear.
The HM pumps are particularly suited to pumping clear and waste water including sewage, containing solids, fibrous solids and sludge.
The single phase model is available with manual or automatic operation, the three phase model has manual operation and features Klixon and water in oil chamber alarm outputs.
The HM has a horizontal DN65 flanged discharge, an optional claw can be fitted for use on guide rails, the maximum flow rate is 1,000 litres per minute, and the maximum head is 22m.
AF Pumps are sold exclusively by Automated Environmental Systems in the UK.
HM DN65 Submersible Sewage Pump with Single Channel Closed Impeller
Product description
The HM DN65 from AF Pumps features tough construction and a single channel closed impeller, offering reliability against clogging, the DN65 flange offers wide through sections, with 40mm free passage and good resistance to wear.
The HM pumps are particularly suited to pumping clear and waste water including sewage, containing solids, fibrous solids and sludge.
The single phase model is available with manual or automatic operation, the three phase model has manual operation and features Klixon and water in oil chamber alarm outputs.
The HM has a horizontal DN65 flanged discharge, an optional claw can be fitted for use on guide rails, the maximum flow rate is 1,000 litres per minute, and the maximum head is 22m.
AF Pumps are sold exclusively by Automated Environmental Systems in the UK.
Key features
Maximum flow 1,000 litres per minute, maximum head 22m
Maximum temperature of pumped fluid 40°C
PH of pumped fluid 6-10
DN65 discharge offers reliability against clogging
Single channel closed impeller
Free passage up to 40mm
230v manual and automatic operation, 400v manual operation
Three phase models feature Klixon and water in oil chamber alarm outputs
Single-phase motor protector and capacitor in box control, three-phase with compulsory protection to be provided by the user
For more information on the full Poolstar pool, spa and wellness range or to speak to us about becoming a stockist please call 01284 658770 or email our sales team.
We are proud to be the official UK & Ireland Poolstar distribution partner.
The HM DN65 from AF Pumps features tough construction and a single channel closed impeller, offering reliability against clogging, the DN65 flange offers wide through sections, with 40mm free passage and good resistance to wear.
The HM pumps are particularly suited to pumping clear and waste water including sewage, containing solids, fibrous solids and sludge.
The single phase model is available with manual or automatic operation, the three phase model has manual operation and features Klixon and water in oil chamber alarm outputs.
The HM has a horizontal DN65 flanged discharge, an optional claw can be fitted for use on guide rails, the maximum flow rate is 1,000 litres per minute, and the maximum head is 22m.
AF Pumps are sold exclusively by Automated Environmental Systems in the UK.
Key features
Maximum flow 1,000 litres per minute, maximum head 22m
Maximum temperature of pumped fluid 40°C
PH of pumped fluid 6-10
DN65 discharge offers reliability against clogging
Single channel closed impeller
Free passage up to 40mm
230v manual and automatic operation, 400v manual operation
Three phase models feature Klixon and water in oil chamber alarm outputs
Single-phase motor protector and capacitor in box control, three-phase with compulsory protection to be provided by the user
Electric cable neoprene H07RN8-F with free therminals
Bolt A2 class AISI 304
O’ring nitrile
Shaft sealing by two mechanical seals mounted in series in ecologic oil chamber
Seal types applied to the motor side on ceramic/graphite and seal types applied to the wet end side on silicon carbide
Motor asynchronous squirrel cage type in dielectric anti-oxide oil bath
Protection IP 68 and insulation class F
