Key features
Compact and quick to install – cell has unions at both ends and the control box is mounted on two screws
50mm / 1½ inch water connections
Improved linear water flow within the cell (can be mounted horizontally or vertically)
Extended cell life with no knife edge erosion
Virtually zero maintenance
Clear housing allows easy monitoring of electrodes and chlorine production
Cell housing withstands in excess of 4 bar under test
Inline water strainer prevents particles lodging between plates
Water monitoring for optimum chlorine output & cell life
All top quality titanium parts, fully serviceable cell
Power supply efficiency better than 80%, reduced electricity costs and longer equipment life
Aluminium enclosure is lightweight, corrosion resistant and provides better heat dissipation
Short circuit and overload protected – cannot be damaged by overdosing with salt
Automatic salt concentration and cell function monitoring
Fixed current output, timer controlled, allows chlorine output to be accurately adjusted even for very small pools while ensuring maximum cell life
Soft-start capability to protect electrode coating at switch-on and at polarity reversal
Advanced reversal circuitry
Two year warranty
Downloads
Specifications (.pdf)
Manual (.pdf)
Troubleshooting Guide (.pdf)
Specifications
Maximum Pool Size |
Up to 50,000 litres |
Chlorine Output |
10g/h at 0.4% NaCl |
Running Power |
less than 50w |
Electrode Coating Life |
10,000 hours |
Salt type |
High purity salt NOT iodized salt |
Maximum Pressure |
4 Bar |
Maximum Pool Size |
Up to 100,000 litres |
Chlorine Output |
20g/h at 0.4% NaCl |
Running Power |
less than 80w |
Electrode Coating Life |
10,000 hours |
Salt type |
High purity salt NOT iodized salt |
Maximum Pressure |
4 Bar |
Maximum Pool Size |
Up to 150,000 litres |
Chlorine Output |
30g/h at 0.4% NaCl |
Running Power |
less than 120w |
Electrode Coating Life |
10,000 hours |
Salt type |
High purity salt NOT iodized salt |
Maximum Pressure |
4 Bar |
What is salt water chlorination?
Salt water chlorination is the healthy alternative to chlorinating your swimming pool using chemicals. Coarse salt is added to your pool to form a mildly saline solution, the salinity is kept at a low level, typically less than one fifth of sea water.
The Saline Blue works by producing chlorine in low concentrations whenever the pump and filter is running, chlorine is produced by electrolysis of the pool water as it flows through the cell and returns to the pool.
A major advantage of the Saline Blue system is that the chlorine produced has no effect on the pool water’s pH, alkalinity or hardness, which is not the case with other chlorination methods, making it easier and cheaper to keep pool water in balance.
By automatically chlorinating a swimming pool this way, many of the problems associated with other chlorination methods, are eliminated. The process is safe, effective, economical, and healthy and requires only minimum maintenance.
High purity salt is recommended
Iodized salt is NOT suitable
Higher salt concentrations = longer cell life and higher chlorine output
Lower salt concentrations = reduced cell life and poor chlorine output
The transition between ‘salt low’ and ‘salt ok’ is set to occur below 0.4%
Always keep your salt levels above 0.5% for best performance
