Key features
Domestic, agricultural, industrial, irrigation – transfer and pressure washing
Permanent or transportable
Float switch control for automatic pump operation
Excellent resistance to abrasion from sand
Downloads
Specifications (.pdf)
Manual (.pdf)
Technical data
Maximum fluid temperature: 35°C
Sand content capacity: 60 g/m3
Maximum number of start-up times: 30 per hour
Pump casing in stainless steel (AISI304)
Radial Centrifugal Turbine Stainless Steel (AISI 304)
Shaft in stainless steel (AISI 416)
Diffuser in glass fibre reinforced NORYL
Externally cooled by the pumped liquid
Cooled with mineral oil for alimentary use, non-toxic, non-pollutant
Mechanical seal (aluminium axide-carbon-graphite)
Mechanical seal (SIC/SIC DIN24960) on request
Protection IP58
20m power cord
Tension standard
Class F insulation
