Key features
Suitable for water boosting and circulation, rainwater harvesting systems, sprinkling and irrigation, feeding and emptying tanks, industrial washing, domestic, commercial and industrial use
Manual (MO) or automatic (AMO) versions
Surface, or submerged installation
Suitable for clean water, free from solid and abrasive substances
Automatic version (AMO) includes built-in pressure sensor, anti-blocking & run dry protection
Main flanges in brass for extra longevity and durability against heat/frost
10 metre mains cable with three-pin plug
Maximum depth 5m
Downloads
Specifications
Model
|
X-AMO 120 |
Flowrate Max.
|
100 L/min |
Head Max.
|
52m |
Power (P2 nominal)
|
0.9 kW |
Voltage
|
230V |
Water Temp Max.
|
37°C |
Discharge Size
|
1¼ inch |
Pumped Medium
|
Clean water |
Weight
|
17 Kg |
Dimensions (H x W x L)
|
226mm x 200mm x 477mm |
Technical data
Pump body: stainless steel AISI 304
Motor body: stainless steel AISI 304
Shaft: stainless steel AISI 420
Impellers: stainless steel AISI 304
Diffuser and Venturi Jet: Noryl
Mechanical Seal: Ceramic Graphite
Mechanical seal lubricated by a special oil chamber
A2 Stainless steel bolts
NBR70 O-ring
Protection class: IP 68
Tropicalised circuit board in compliance with the RoHS directive
Pumped liquid temperature: +2°C to +37°C
