If you would like more information on our range of Poolstar products, including Poolex Spawer heat pumps, Holl's saunas, NetSpa ice baths and Formidra showers, you can talk to our team on 01284 658770 or send us an email.
We are proud to be the official UK & Ireland Poolstar distribution partner.
The Saci Magnus swimming pool pump is a high flow self-priming pump with a large pre-filter capability, which, together with an excellent hydraulic performance, gives a very large filtering capacity, making it suitable for commercial and community swimming pools.
The flanged connections and broad base make these pumps especially robust which together with their excellent chemical resistance makes them ideally suited to pools with large filtration systems.
The Magnus 4 has a four pole motor with a speed of 1,450RPM and the Magnus 2 has a two pole motor with a speed of 2,850RPM, all models require 400v three phase power. In addition, the Magnus 4 offers extremely quiet operation.
The Magnus series has models ranging from 3.0HP to 15HP, models come fitted with a Noryl or bronze (B) impeller.
Super quiet pumps ( four pole motors)
High volume self-priming pump that is ideally suited to larger filtration systems
Large suction side pre-filter
Excellent hydraulic performance
Filter with polycarbonate cover for easy viewing of filter basket contents
Large polythene pre-filter prevents floating debris from damaging the pump or connected equipment
Flanged connections and broad base make the system especially robust
Excellent chemical resistance
Noryl or Bronze (B) impeller
Model |
Magnus-4 300 |
Flowrate Max. |
1,033 L/min |
Head Max. |
14m |
Horse Power |
3.0 HP |
Power Output |
2.2 kW |
Voltage |
400V |
Water Temp Max. |
40°C |
Motor Speed |
1450 RPM |
Discharge Size |
DN100 Flange |
Suction Size |
DN100 Flange |
Weight |
42.5 Kg |
Dimensions (H x W x L) |
590mm x 370mm x 840mm |
Model |
Magnus-4 400 |
Flowrate Max. |
1,233 L/min |
Head Max. |
16m |
Horse Power |
4.0 HP |
Power Output |
3.0 kW |
Voltage |
400V |
Water Temp Max. |
40°C |
Motor Speed |
1450 RPM |
Discharge Size |
DN100 Flange |
Suction Size |
DN100 Flange |
Weight |
44.5 Kg |
Dimensions (H x W x L) |
590mm x 370mm x 840mm |
Model |
Magnus-4 550 |
Flowrate Max. |
2,050 L/min |
Head Max. |
14m |
Horse Power |
5.5 HP |
Power Output |
4.0 kW |
Voltage |
400V |
Water Temp Max. |
40°C |
Motor Speed |
1450 RPM |
Discharge Size |
DN100 Flange |
Suction Size |
DN100 Flange |
Weight |
53.4 Kg |
Dimensions (H x W x L) |
590mm x 370mm x 1170mm |
Model |
Magnus-4 750 |
Flowrate Max. |
2,383 L/min |
Head Max. |
16m |
Horse Power |
7.5 HP |
Power Output |
5.5 kW |
Voltage |
400V |
Water Temp Max. |
40°C |
Motor Speed |
1450 RPM |
Discharge Size |
DN100 Flange |
Suction Size |
DN100 Flange |
Weight |
66 Kg |
Dimensions (H x W x L) |
590mm x 370mm x 1170mm |
Model |
Magnus-4 1000 |
Flowrate Max. |
2,666 L/min |
Head Max. |
18m |
Horse Power |
10 HP |
Power Output |
7.5 kW |
Voltage |
400V |
Water Temp Max. |
40°C |
Motor Speed |
1450 RPM |
Discharge Size |
DN100 Flange |
Suction Size |
DN100 Flange |
Weight |
76 Kg |
Dimensions (H x W x L) |
590mm x 370mm x 1170mm |
Model |
Magnus-2 1250 |
Flowrate Max. |
2,783 L/min |
Head Max. |
20m |
Horse Power |
12.5 HP |
Power Output |
9.2 kW |
Voltage |
400V |
Water Temp Max. |
40°C |
Motor Speed |
2850 RPM |
Discharge Size |
DN100 Flange |
Suction Size |
DN100 Flange |
Weight |
84.5 Kg |
Dimensions (H x W x L) |
590mm x 370mm x 1170mm |
Model |
Magnus-2 1500 |
Flowrate Max. |
3,133 L/min |
Head Max. |
22m |
Horse Power |
15 HP |
Power Output |
11 kW |
Voltage |
400V |
Water Temp Max. |
40°C |
Motor Speed |
2850 RPM |
Discharge Size |
DN100 Flange |
Suction Size |
DN100 Flange |
Weight |
85.5 Kg |
Dimensions (H x W x L) |
590mm x 370mm x 1170mm |
Pre-filter body, pump body, volute, counter-volute and cover in glass-fibre loaded polypropylene resistant to pool chemicals
Mechanical seal in ceramic carbon and AISI 316 Stainless Steel (ready to work with seawater)
Noryl impeller / bronze impeller (B) with AISI Stainless Steel shaft and screws
Insulation: Class F
IP55 protection
Motor bearings greased for pump lifespan
DN100 (110mm) flanged suction and discharge (DN100 counter-flange kit available separately)
Two year warranty
