The Tecno 6-11 from AF Pumps is a medium to heavy duty submersible drainage pump that is suitable for domestic and civil drainage applications. Designed and manufactured in Italy, the Tecno are hard-wearing and dependable pumps.
The Tecno can be used on construction sites, for de-watering civil and industrial waste water, emptying out sumps and water recirculation in manufacturing and industry.
Construction is cast iron and the pump has an open multi-vane fully submerged impeller, suitable for handling clear and slightly dirty water containing small solids up to 22mm.
The Tecno has a maximum flow rate of 580 litres per minute and a maximum head of 19m, the pumps are available in 230v single phase and 400v three phase with a choice of manual or automatic (with attached float switch) operation.
Maximum flow 580 litres per minute, maximum head 19m
Maximum temperature of pumped fluid 40°C
PH of pumped fluid 6-10
Clear or slightly dirty water
1¼ inch to 2 inch discharge
Open multi-vane fully submerged impeller
Free passage up to 22mm
230v or 400v manual and automatic versions
Single phase models feature built-in capacitor motor protection, three-phase models require external capacitor protection (not provided)
Optional kit for mounting on guide rail systems
Flowrate Max. |
450 L/min |
Head Max. |
10m |
Impeller Type |
Multi-vane |
Horse Power |
1.0 HP |
Power |
0.75 kW |
Voltage |
230V (M)(MG) or 400V (T)(TG) |
Water Level Max. |
20m |
Operation |
Manual (M)(T) or Automatic with float (MG)(TG) |
Motor Speed |
2850 RPM |
Discharge Size |
2 Inch |
Free Passage |
17mm |
Pumped Medium |
Clean and slightly dirty water |
Cable Length |
10m |
Construction |
Cast iron |
Weight |
15.5 Kg |
Dimensions (H x W x L) |
345mm x 170mm x 210mm |
Flowrate Max. |
580 L/min |
Head Max. |
15m |
Impeller Type |
Multi-vane |
Horse Power |
1.5 HP |
Power |
1.1 kW |
Voltage |
230V (M)(MG) or 400V (T)(TG) |
Water Level Max. |
20m |
Operation |
Manual (M)(T) or Automatic with float (MG)(TG) |
Motor Speed |
2850 RPM |
Discharge Size |
2 Inch |
Free Passage |
22mm |
Pumped Medium |
Clean and slightly dirty water |
Cable Length |
10m |
Construction |
Cast iron |
Weight |
20.5 Kg |
Dimensions (H x W x L) |
379mm x 170mm x 210mm |
Flowrate Max. |
670 L/min |
Head Max. |
17m |
Impeller Type |
Multi-vane |
Horse Power |
2.0 HP |
Power |
1.5 kW |
Voltage |
230V (M)(MG) or 400V (T)(TG) |
Water Level Max. |
20m |
Operation |
Manual (M)(T) or Automatic with float (MG)(TG) |
Motor Speed |
2850 RPM |
Discharge Size |
2 Inch |
Free Passage |
22mm |
Pumped Medium |
Clean and slightly dirty water |
Cable Length |
10m |
Construction |
Cast iron |
Weight |
22.5 Kg |
Dimensions (H x W x L) |
379mm x 170mm x 210mm |
Flowrate Max. |
490 L/min |
Head Max. |
18m |
Impeller Type |
Multi-vane |
Horse Power |
1.5 HP |
Power |
1.1 kW |
Voltage |
230V (M)(MG) or 400V (T)(TG) |
Water Level Max. |
20m |
Operation |
Manual (M)(T) or Automatic with float (MG)(TG) |
Motor Speed |
2850 RPM |
Discharge Size |
1½ Inch |
Free Passage |
22mm |
Pumped Medium |
Clean and slightly dirty water |
Cable Length |
10m |
Construction |
Cast iron |
Weight |
18.5 Kg |
Dimensions (H x W x L) |
363mm x 164mm x 188mm |
Flowrate Max. |
580 L/min |
Head Max. |
19m |
Impeller Type |
Multi-vane |
Horse Power |
2.0 HP |
Power |
1.5 kW |
Voltage |
230V (M)(MG) or 400V (T)(TG) |
Water Level Max. |
20m |
Operation |
Manual (M)(T) or Automatic with float (MG)(TG) |
Motor Speed |
2850 RPM |
Discharge Size |
1½ Inch |
Free Passage |
22mm |
Pumped Medium |
Clean and slightly dirty water |
Cable Length |
10m |
Construction |
Cast iron |
Weight |
20.5 Kg |
Dimensions (H x W x L) |
363mm x 164mm x 188mm |
Motor housing Cast iron GG 25
Shaft stainless steel AISI 420
Electric cable neoprene H07RN8-F oil resistant
Bolt A2 class AISI 304
O’ring and lip seal nitrile
Mechanical seal on silicon carbide + allumina
Motor asynchronous squirrel cage type in dielectric anti-oxide oil bath
Protection IP 68 and insulation class F
