Product overview

The Tecno 1-5 from AF Pumps is a heavy duty Italian made cast iron submersible drainage pump capable of handling clear and slightly dirty water up to 580 litres per minute with a maximum 19m head.

Highlights

Designed and manufactured in Italy using cast iron for hard wearing, long lasting performance

Open multi-vane submerged impeller handles clear and slightly dirty water containing solids up to 22mm

High volume drainage capabilities offering flow rates up to 580 litres per minute and a maximum head of 19m

Versatile 1¼ inch to 2 inch discharge outlets to suit various pipe connections

Available in 230v single-phase or 400v three-phase options with a choice of manual or automatic float switch operation

Built-in capacitor motor protection on single-phase models prevents thermal overload and damage

Compatible with optional guide rail mounting kits for simple installation and easy maintenance access

Suitable for fluid temperatures up to 40°C and a pH range between 6 and 10

Details

Motor housing Cast iron GG 25

Shaft stainless steel AISI 420

Electric cable neoprene H07RN8-F oil resistant

Bolt A2 class AISI 304

O’ring and lip seal nitrile

Mechanical seal on silicon carbide + allumina

Motor asynchronous squirrel cage type in dielectric anti-oxide oil bath

Protection IP 68 and insulation class F

Specifications

Flowrate Max.
190 L/min
Head Max.
8m
Impeller Type
Multi-vane
Horse Power
0.4 HP
Power
0.3 kW
Voltage
230V (M)(MG) or 400V (T)
Water Level Max.
20m
Operation
Manual (M)(T) or Automatic with float (MG)
Motor Speed
2850 RPM
Discharge Size
1¼ Inch
Free Passage
12mm
Pumped Medium
Clean and slightly dirty water
Cable Length
5m
Construction
Cast iron
Weight
9.5 Kg
Dimensions (H x W x L)
263mm x 135mm x 151mm
Flowrate Max.
215 L/min
Head Max.
9m
Impeller Type
Multi-vane
Horse Power
0.5 HP
Power
0.37 kW
Voltage
230V (M)(MG) or 400V (T)
Water Level Max.
20m
Operation
Manual (M)(T) or Automatic with float (MG)
Motor Speed
2850 RPM
Discharge Size
1¼ Inch
Free Passage
12mm
Pumped Medium
Clean and slightly dirty water
Cable Length
5m
Construction
Cast iron
Weight
10 Kg
Dimensions (H x W x L)
263mm x 135mm x 151mm
Flowrate Max.
325 L/min
Head Max.
10m
Impeller Type
Multi-vane
Horse Power
0.8 HP
Power
0.6 kW
Voltage
230V (M)(MG) or 400V (T)(TG)
Water Level Max.
20m
Operation
Manual (M)(T) or Automatic with float (MG)(TG)
Motor Speed
2850 RPM
Discharge Size
1½ Inch
Free Passage
17mm
Pumped Medium
Clean and slightly dirty water
Cable Length
10m
Construction
Cast iron
Weight
13.5 Kg
Dimensions (H x W x L)
317mm x 164mm x 188mm
Flowrate Max.
380 L/min
Head Max.
12m
Impeller Type
Multi-vane
Horse Power
1.0 HP
Power
0.75 kW
Voltage
230V (M)(MG) or 400V (T)(TG)
Water Level Max.
20m
Operation
Manual (M)(T) or Automatic with float (MG)(TG)
Motor Speed
2850 RPM
Discharge Size
1½ Inch
Free Passage
17mm
Pumped Medium
Clean and slightly dirty water
Cable Length
10m
Construction
Cast iron
Weight
14.5 Kg
Dimensions (H x W x L)
317mm x 164mm x 188mm
Flowrate Max.
360 L/min
Head Max.
8m
Impeller Type
Multi-vane
Horse Power
0.8 HP
Power
0.6 kW
Voltage
230V (M)(MG) or 400V (T)(TG)
Water Level Max.
20m
Operation
Manual (M)(T) or Automatic with float (MG)(TG)
Motor Speed
2850 RPM
Discharge Size
2 Inch
Free Passage
17mm
Pumped Medium
Clean and slightly dirty water
Cable Length
10m
Construction
Cast iron
Weight
14.5 Kg
Dimensions (H x W x L)
345mm x 170mm x 210mm
