Key features
Lifting and distribution of water in domestic systems in continuous or intermittent operation
Pressurization systems
Washing, garden irrigation, supply to fountains, transfers
Lifting from wells or tanks
Clean water without suspended solid bodies or abrasive material
Maximum temperature of the liquid 50°C
Maximum recommended suction height 8m with foot valve
Maximum operating pressure 6 bar (10 bar for JET 100 – 160)
Downloads
Specifications (.pdf)
Technical data
Enclosed, externally ventilated motor
Level of protection IP 44
Class F insulation
Single phase power supply with capacitor permanently activated and thermal protection built into the motor winding
Three phase power supply with external protection provided by the user
Speed of rotation 2850 rpm
Suitable for continuous use
