Key features
Made from anti-corrosive and dust-proof materials
Integrated float switch makes pump suitable for use in narrow spaces
Low suction capability down to 2/3mm
Suitable for use with water containing particles up to 5mm
Very low priming and starting level of the pump: 10–15mm (manual operation), 165mm (automatic operation)
Selector for manual or automatic operation
Easy access, through sliding cover, to float switch for cleaning
Motor with thermal overload protection
Excellent cooling of the motor that enables the pump to operate even when it is partially submerged
10 metre mains cable and moulded UK plug (110v model is not supplied with plug)
1¼ inch top discharge, four-step hose tail supplied
Downloads
Specifications (.pdf)
Manual (.pdf)
Specifications
Model |
200M |
Operation |
Automatic (integral float) |
Float Start Height |
165mm |
Float Stop Height |
65mm |
Flowrate Max. |
145 L/min |
Head Max. |
6m |
Impeller Type |
Vortex |
Horse Power |
0.28 HP |
Power |
0.2 kW |
Voltage |
230V |
Water Level Min. |
2/3mm |
Water Temp Max. |
35°C |
Motor Speed |
2800 RPM |
Discharge Size |
1¼ inch |
Free Passage |
5mm |
Pumped Medium |
Water & small particles up to 5mm |
Cable Length |
10m |
Construction |
Technopolymer |
Weight |
4.2 Kg |
Dimensions (H x W x L) |
400mm x 158mm x 225mm |
Model |
400M |
Operation |
Automatic (integral float) |
Float Start Height |
165mm |
Float Stop Height |
65mm |
Flowrate Max. |
180 L/min |
Head Max. |
9m |
Impeller Type |
Vortex |
Horse Power |
0.55 HP |
Power |
0.4 kW |
Voltage |
230V |
Water Level Min. |
2/3mm |
Water Temp Max. |
35°C |
Motor Speed |
2800 RPM |
Discharge Size |
1¼ inch |
Free Passage |
5mm |
Pumped Medium |
Water & small particles up to 5mm |
Cable Length |
10m |
Construction |
Technopolymer |
Weight |
5.1 Kg |
Dimensions (H x W x L) |
400mm x 158mm x 225mm |
Model |
400 |
Operation |
Automatic (integral float) |
Float Start Height |
165mm |
Float Stop Height |
65mm |
Flowrate Max. |
180 L/min |
Head Max. |
9m |
Impeller Type |
Vortex |
Horse Power |
0.55 HP |
Power |
0.4 kW |
Voltage |
110V |
Water Level Min. |
2/3mm |
Water Temp Max. |
35°C |
Motor Speed |
2800 RPM |
Discharge Size |
1¼ inch |
Free Passage |
5mm |
Pumped Medium |
Water & small particles up to 5mm |
Cable Length |
10m |
Construction |
Technopolymer |
Weight |
5.1 Kg |
Dimensions (H x W x L) |
400mm x 158mm x 225mm |
Technical data
Operating range: from 1 to 10m³/h with head up to 9 metres.
Liquid temperature range: from 0 °C to +35 °C for domestic use
Pumped liquid: dirty water without fibres
Pump priming limit: 10-15 mm in manual operation.
Max. immersion depth: 7 metres
Construction features
Hydro resistant technopolymer pump body, cover, and suction grid
Stainless steel motor, roto shaft, and bolts and screws
Threefold seal with interposed rings with oil pre-chamber
Motor features
Submersible type continuous duty asynchronous motor
Stator enclosed in airtight stainless steel casing, with an outer cover that protects the wiring and the capacitor
Rotor running on permanently lubricated ball bearings, oversized to ensure low noise and durability
Built-in thermal-amperometric protection and permanently connected capacitor
