Key features
CPU functions and alarms management
Blue display for parameters
Battery charger/maintainer for acid/lead/gel batteries
Load start with external contact
Short circuit and overload protection
Battery polarity inversion protection
Mains failure alarm
Battery fault alarm
Load fault alarm
Available in grey colour (RAL 7032)
Modular battery holder, made of AISI 304 stainless steel, is anti-corrosion to prevent oxidation or spills from lead batteries
Front access to the battery by the removable door
Please note the Power Box 2200 comes supplied with two ah95 12v batteries, two battery holders and battery connecting cable
Downloads
General features
Power supply for two pumps with alternating duty (230v)
Automatic/manual start and stop buttons
Green LED for running indication
Blue LED for mains supply indication
Auxiliary circuit protection fuses
Main disconnect switch with door lock
Metallic box with side hinges
12V output
Batteries
Batteries are suitable for closed environments, AGM technology prevents acid spills and harmful emissions. Sizes are (H x L x W).
Ah60 (242 x 175 x 190mm) – Supplied with Power Box Pump 500 and 750
Ah80 (310 x 175 x 190mm) – Supplied with Power Box Pump 1100 and 1500
Ah95 x 2 (353 x 175 x 190mm) – Supplied with Power Box Pump 2200
